GL400B

Frequency-MHz 400-480
Bandwidth-MHz 28
Gain-dBi 12
Vertical Beamwidth-o 32
Horizontal Beamwidth-o 36
F/B Ratio-dB ≥18
VSWR ≤1.5
Nominal Impedance-Ω 50
Polarization Vertical or Horizontal
Maximum Power-W 100
Length-m 1.5
Weight-kg 1
Rated Wind Velocity-m/s 60
Connector N Female or Customization

EMAIL

Frequency-MHz 400-480 Bandwidth-MHz 28 Gain-dBi 12 Vertical Beamwidth-o 32 Horizontal Beamwidth-o 36 F/B Ratio-dB ≥18 VSWR ≤1.5 Nominal Impedance-Ω 50 Polarization Vertical or Horizontal Maximum Power-W 100 Length-m 1.5 Weight-kg 1 Rated Wind Velocity-m/s 60 Connector N Female or Customization
