Dual-Band 700-960/1710-6000MHz 6dBi Omnidirectional Antenna GL607

Frequency Range：1710-6000MHz
Gain：6dBi
SMA male connector
Product description: Wideband Coverage Supporting dual frequency bands of 700–960MHz and 1710–6000MHz, it is compatible with multiple communication standards, including LTE, 4G, and select 5G bands.
INQUIRY

Electrical specifications
Frequency (MHz)	700-960MHz/1710-6000MHz
V.S.W.R	2.0 Max
Peak Gain (dBi)	6dBi
Impendance (Ohm)	50 Ohm Nominal
Mechanical and environmental specifications
Polarisation	Linear
Radiation Pattern	Omni-directional
Connector	SMA Male
Cable Type	302
Dimensions (mm)	122.5*45
Material	ASA
Operating Temp	-40°C to 85°C
Storage Temp/Humidity	25±5°C / <70%

Product Introduction

1. Wide Band Coverage

Supports dual frequency bands of 700–960MHz and 1710–6000MHz, suitable for multiple communication standards, including LTE, 4G, and select 5G bands.

2. High-Gain Omnidirectional Signal

6dBi high gain and an omnidirectional radiation pattern provide 360° uniform coverage, suitable for multi-device access environments.

3. High-Quality Construction and Interface

ASA material housing offers strong weather resistance; SMA male connector paired with 302 cable ensures easy installation and stable connection.

4. Wide Operating Temperature Range

Operating temperature range of -40°C to 85°C, suitable for extreme indoor and outdoor industrial environments.

5. Low Standing Wave Ratio and Standard Impedance

VSWR ≤ 2.0 and 50Ω impedance ensure efficient signal transmission with low reflection loss.

Application Scenarios

Indoor/Outdoor Cellular Signal Enhancement

IoT Device Communications (e.g., Smart Meters, Remote Monitoring)

Industrial Wireless Communication Systems (e.g., Factory Wireless Networks)

Fleet Management and In-Vehicle Communication Systems

Broadband Access Devices and Wireless Router Extensions

FAQ

Q: Does this antenna support 5G?

A: It supports some 5G frequency bands (1710–6000MHz). The specific frequency band configuration depends on the local 5G frequency band.

Q: Is the antenna waterproof?

A: The documentation does not clearly indicate the waterproof rating. We recommend using it indoors or with a protective cover for use in humid environments.

Q: Is a mounting bracket included?

A: The standard product does not include a mounting bracket; it is optional.

Q: What is the cable length?

A: The cable length is not specified in the documentation. Please contact customer service to confirm custom options.

Q: Can it be used for in-vehicle communication?

A: Yes. Its omnidirectional characteristics and wide operating temperature range make it ideal for mobile communication environments in vehicles.

Q: What is the antenna impedance?

A: Standard 50 ohms, suitable for most communication equipment.
