GL174862

Item 3-Element Antenna PN GL174862 Frequency Range 174?230/470?862 (MHz) Input Impedance 75(Ω) Half-power Beamwidth H 60±5° / E 66±5° Voltage Standing Wave Ratio (VSWR) ≤2.0(665) Gain 28 (dBi) Maximum Input Power 50 (W) Noise Figure ≤1.5 dB Power Supply Voltage DC 5 V Current ≤30 mA Front-to-back Ratio ≥15 dB Polarization Type Vertical or Horizontal Connector Model F-type female Lightning Protection DC Grounding Operating Temperature -40℃\~﹢65℃ Weight 0.12 (kg) Antenna Dimensions 185×170 (mm) Radiating Elements 3
