GL-BV1703

Frequency Range 806-960MHz No.of Elements 17 VSWR ≤1.7 Impedance 50 Ω Gain 17.5 ±1dBi Polarization Vertical or Horizontal Beam Width H(half-power) 25±5 ° Beam Width V(half-power) 20±2 ° Electrical Downtilt 0 Front to Back Ratio ≥20 Max.Power 100w Connector N-Female Dimension 1500x250x382mm Weight 1.6Kg Rated Wind Speed 150km/h Radome Material Aluminium Diameter of installation pole Φ30-Φ53mm
