GPS External Antenna

  • GPSGLONASS antenna with Fakra H connector
  • GPSGLONASS antenna with Fakra H connector
GPSGLONASS antenna with Fakra H connector GPSGLONASS antenna with Fakra H connector

GPSGLONASS antenna with Fakra H connector

  • P/N: GL-DY003FH
  • Cable: RG174,0.3m
  • Connector: Fakra H
  • Mounting: Screw
  • Product description: This application shall apply for antenna unit which shall be used with an engine for an automobile
  • INQUIRY


FOB Port: Shanghai or Shenzhen

MOQ: 500PCS


Supply Ability:5000 Pcs/Day


Payment: TT,Paypal,Western Union


Download Info: here


GPSGlonass Antenna

GL-DY003FH

Electrical Index

Frequency-MHz

1575.42-1610

VSWR

1.5

Nominal Impedance-Ω

50

Polarization

RHCP,

Axial Ratio

3dB(max)

LNA Gain

28±2dB

Noise Figure

1.5

Supply Voltage

3-5V DC

Current Consumption

5-15mA

Mechanical Index

Cable Length

RG174,0.3m

Connector

Fakra D

Antenna Dimension-mm

46.6*14.5

Installation Way

Screw

Ingress Protection

IP65~IP67(exclude cable outlet)

Vibration

10 to 55Hz with 1.5mm amplitude 2hours

Environmentally Friendly

ROHS Compliant

Temperature-

-40~+85

Humidity-

595

FAQ

Q: Can I get one sample?

A: Yes, sample is available.


Q: Have GNSS antenna 100% assembles well in stock?

A: No, all GNSS antenna will be newly assembled according to your orders including the samples.


Q: What's the delivery time?

A: 3-5 working days for the sample, 10-15 working days for quantity below 5K,.


Q: Could i use my own LOGO or design on goods?

A: Yes, customized logo and design on mass production are available.


Q: What's the payment term?

A:T/T, Paypal, western union etc.


Q:May I visit your company?

A: Sure, welcome any time.


Q: How long of the warranty?

A: one year for antennas and half a year for assembly cables and Connectors
