GL-DY070 - A 3-in-1 integrated shark fin antenna combining GPS, GSM, and AM/FM functionalities for multi-protocol device integration.
This integrated antenna solution combines GPS positioning, cellular communication, and broadcast reception in a single robust housing. Designed for vehicle tracking, telematics, fleet management, and IoT applications with IP65-IP66 protection and wide temperature range operation.
Key Features | |
3-in-1 Integration Combines GPS, GSM, and AM/FM antennas in single housing, reducing installation complexity. | High Performance GPS GPS LNA with 28±2 dB gain, <1.5 noise figure, and excellent out-of-band rejection. |
Global Cellular Support GSM antenna covers 824-960MHz and 1710-1990MHz bands for worldwide connectivity. | Active AM/FM Reception High-gain active antenna: 20dBi for FM, 12dBi for AM with 12V DC supply. |
Robust Environmental Protection IP65-IP66 rated, operates at -40℃ to +85℃, up to 95% humidity, vibration resistant. | Compliance & Safety ROHS compliant, DC ground lightning protection, environmentally friendly design. |
| System | Parameter | Specification |
|---|---|---|
| GPS Antenna | Center Frequency | 1575.42 ± 1 MHz |
| Band Width | CF ± 5 MHz | |
| Polarization | RHCP (Right Hand Circular Polarization) | |
| Gain | 2 dBic (Zenith) | |
| V.S.W.R | < 1.5 | |
| Axial Ratio | 3 dB (max) | |
| Impedance | 50 Ω | |
| GPS LNA | Gain | 28 ± 2 dB |
| Noise Figure | < 1.5 | |
| Ex-band Attenuation | 12 dB @ CF+50MHz / 16 dB @ CF-50MHz | |
| V.S.W.R | < 2.0 | |
| GSM Antenna | Frequency Range | 824-960 MHz / 1710-1990 MHz |
| V.S.W.R | < 2.5 | |
| Polarization | Linear | |
| Gain | 2 dBi | |
| Impedance | 50 Ω | |
| Electrical | Supply Voltage | 2.2~5V DC |
| Current Consumption | 5~15 mA | |
| Supply Voltage (FM/AM) | 12V DC | |
| FM/AM Antenna | Frequency Range | 520-1629 KHz (AM) / 76-108 MHz (FM) |
| V.S.W.R | < 2.5 | |
| Polarization | Linear | |
| Gain | 20 dBi (FM) / 12 dBi (AM) | |
| Impedance | 50 Ω | |
| Environmental | Operating Temperature | -40℃ ~ +85℃ |
| Relative Humidity | Up to 95% | |
| Ingress Protection | IP65~IP66 (exclude cable outlet) | |
| Vibration Test | 10 to 55Hz with 1.5mm amplitude, 2 hours | |
| Compliance | Environmental Compliance | ROHS Compliant |
Vehicle Tracking and Telematics Systems
Fleet Management and Logistics Solutions
IoT Devices and M2M Communication
Marine and Aviation Navigation Systems
Mobile Data Collection and Remote Monitoring
Emergency Response and Public Safety Vehicles
|
|
Request Quote Request Sample Download PDF
MOQ 50 units | Lead Time 1-2 weeks | Warranty 1 year |
The GL-DY070 is a 3-in-1 integrated shark fin antenna. It combines GPS, GSM, and AM/FM functionalities into a single housing, allowing you to replace three separate antennas with one mounting point. This reduces RF cable clutter and simplifies the mechanical design of your vehicle or terminal.
To ensure high-precision positioning even in weak signal areas, the GPS LNA provides:
High Gain: 28±2 dB
Low Noise: Noise Figure <1.5
Excellent Rejection: Ex-band attenuation of 12dB@CF+50MHz and 16dB@CF-50MHz to prevent interference from nearby cellular transmitters
Flexible Power: Supports a supply voltage from 2.2V to 5V DC
The GSM antenna is optimized for global dual-band operations, covering 824~960MHz and 1710~1990MHz. It maintains a V.S.W.R <2.5 and an impedance of 50Ω across these ranges to ensure stable data transmission.
It is an active antenna requiring a 12V DC supply. This amplification provides a significant gain of 20dBi for FM and 12dBi for AM, ensuring clear signal reception even in remote areas where passive whip antennas might fail.
