GLTLMR200

Cable?Construction No Material?quality Dimensions 1.Inner Conductor Bare Copper Φ±0.02mm 2.Insulation Foam FPE Ф±0.1mm 3.Outer Conductor Dual AI Foil Ф±0.1mm 4.Braid Tinned Copper or aluminum magnesium alloy braiding Ф±0.1mm 5.Jacket PVC or PE Φ±0.1mm Mechanical Characteristics and Electrical Performance Parameters Impedance 50±2Ω Capacitance 80.4±2PF/M Velocity 83% Peak?Power 2.5KW Inner?Conductor?Dc?resistance ≥17.59ohms/1000m Outer?Conductor?Dc?resistance ≥16.8ohms/1000m Cutoff?Frequency 39GHz Operating?Temperature?(℃) -40~+85℃ VSWR DC~6GHz <1.25
