GL500Z9

Frequency(Mhz) 480-590
Bandwidth(MHz) 30
Gain(dBi) 9
Vertical?Beamwidth(°) 48
Horizontal Beamwidth(°) 54
F/B?Ratio(dB) ≥15
VSWR ≤1.5
Nominal?Impedance(Ω) 50
Polarization Vertical
Maximum Power(W) 100
Dimensions(mm) 11900
Weight(kg) 0.8
Connector N female or Customization
Material Aluminum alloy

EMAIL

Frequency(Mhz) 480-590 Bandwidth(MHz) 30 Gain(dBi) 9 Vertical?Beamwidth(°) 48 Horizontal Beamwidth(°) 54 F/B?Ratio(dB) ≥15 VSWR ≤1.5 Nominal?Impedance(Ω) 50 Polarization Vertical Maximum Power(W) 100 Dimensions(mm) 11900 Weight(kg) 0.8 Connector N female or Customization Material Aluminum alloy
