GL1500Y8

Frequency(Mhz) 1400-1550
Bandwidth(MHz) 150
Gain(dBi) 12
Vertical?Beamwidth(°) 48
Horizontal Beamwidth(°) 40
F/B Ratio(dB) ≥16
VSWR ≤1.5
Nominal?Impedance(Ω) 50
Polarization Vertical or Horizontal
Maximum Power(W) 100
Dimensions(m) 0.55
Weight(kg) 0.5
Connector N female or Customization
Rated Wind Velocity(m/s) 60
Mounting Mast Diameter(mm) φ30
