GL1200BP65D16

Frequency(Mhz) 1000-1200
Bandwidth(MHz) 200
Gain(dBi) 16
Vertical?Beamwidth(°) 16
Horizontal Beamwidth(°) 90
F/B Ratio(dB) ≥25
VSWR ≤1.5
Nominal?Impedance(Ω) 50
Polarization Vertical
Maximum Power(W) 100
Dimensions(mm) 1300*280*128
Weight(kg) 11
Connector N female
Rated Wind Velocity(m/s) 60
Mounting Mast Diameter(mm) φ50-70

EMAIL

Frequency(Mhz) 1000-1200 Bandwidth(MHz) 200 Gain(dBi) 16 Vertical?Beamwidth(°) 16 Horizontal Beamwidth(°) 90 F/B Ratio(dB) ≥25 VSWR ≤1.5 Nominal?Impedance(Ω) 50 Polarization Vertical Maximum Power(W) 100 Dimensions(mm) 1300*280*128 Weight(kg) 11 Connector N female Rated Wind Velocity(m/s) 60 Mounting Mast Diameter(mm) φ50-70
